Ultrasonic Vascular Doppler Detector ME-520T

Share
documents & resoures

Ultrasonic Vascular Doppler Detector ME-520T


Features:

It is mainly used to detect the blood flow of human or animal arteries and capillaries. Applicable to orthopaedics, surgery, Plastic surgery, burn department, pet hospital, etc.

Product parameters:

Detect the blood stream status of arterial/venous by 8.0MHz.

Detect the blood flow average velocity.

Detect the result of finger/toes and part of body's vein anatomies operation.

It can be used to listen the temporo-mandibular joints (They become noisy when they start to brake because of the bite problems), assist doctor to check the conditions of the joints and predict the result of treatment.

Built-in ARM microprocessor & real-time displays blood flow velocity waveform;

Choose menu by pressing keys, store 50 curves;

High-speed USB port, can be connected directly to computer to analyze, store, and print the waveform.

Detect the pulse rate and show PR simultaneously

PPG probe for option.

Specification:

Ultrasonic frequency: 8.0MHz±10%

Battery: 7.4V/900mAhrechargeable Lithium

Input voltage: DC 9V 1000mA

Doppler frequency: 100--7000Hz

Display: Color LCD  128×96 dots,  display blood stream average velocity, PK, time, volume and battery

Working temperature: 10-40℃

Humidity: ≤80%

Atmospheric pressure: 86--106kPa

Package:

Single Unit    Dimension: 26cm x 25cm x 12cm       Gross Weight: 1.5kg

6 pcs/carton  Dimension: 49cm x 26cm x 33cm       Gross Weight: 8.5kg
